Force Circulation MVR Evaporator

Force Circulation MVR Evaporator (FC MVR System)

The Force Circulation MVR Evaporator (FC MVR) is an advanced evaporation system that combines force circulation technology with mechanical vapor recompression (MVR) for superior energy efficiency and evaporation performance.

This system not only enhances evaporation rates but also significantly reduces energy consumption by reusing the latent heat from vapor condensation.

1. General Description

Force Circulation Technology (FC):
The system employs a high-flow circulation pump to move the liquid through heat exchanger tubes at high velocity.
This prevents scaling, maintains high heat transfer efficiency, and ensures stable operation even with viscous or fouling-prone liquids.
Evaporation occurs when the liquid reaches its boiling point, causing vapor to separate from the liquid phase and move toward the condenser.

Mechanical Vapor Recompression (MVR):
In the MVR process, vapor generated from evaporation is mechanically compressed to increase its temperature and pressure.
The compressed vapor is then reused as a heating medium to further evaporate the solution, recycling the latent heat and minimizing external energy requirements such as steam.

The integration of Force Circulation and MVR technologies enables the FC MVR system to handle difficult-to-evaporate solutions efficiently while dramatically lowering operating energy costs.

2. Applications

Like other evaporator systems, the Force Circulation MVR Evaporator is widely used across multiple industrial sectors, including:

• Food and Beverage: Concentration of liquid foods, juices, dairy, and syrups.

• Pharmaceutical: Concentration of pharmaceutical solutions and heat-sensitive compounds.

• Chemical: Recovery of solvents and concentration of chemical solutions.

• Wastewater Treatment: Particularly effective in industrial wastewater recycling and regeneration, maximizing water recovery with minimal energy input.

Depending on each case, the FC MVR system can be customized and combined with other evaporation or crystallization technologies to achieve optimal performance.
For more details, please explore the evaporator systems supplied by Thinh Vuong Technical Services (TVTS).
